Shock test Ea (DIN IEC 68-2-27)
Shock: 15g
Duration: 11ms
Electromagnetic compatibility
Complies with EN 61 326-1
(for continuous, non-attended operation)
GENERAL
Housing
Material: Makrolon 9415
flame-retardant
Flammability class: UL 94 VO, self-extinguishing
Plug-in module, inserted from the front
Safety test
Complies with EN 61010-1 (VDE 0411-1):
Overvoltage category II
Contamination class 2
Working voltage range 300 V
Protection class II
Certifications
Type-tested to DIN EN 14597 (replaces DIN
3440 )
With the according sensors applicable for:
w
Heat generating plants with outflow
temperatures up to 120°C to
DIN 4751
w
Hot water plants with outflow temperatures
above 110°C to
DIN 4752
w
Thermal transfer plants with organic transfer
media to
DIN 4754
w
Oil-heated plants to
DIN 4755
cULus certification
(Type 1, indoor use)
File: E 208286
Mounting
Panel mounting with two fixing clamps at
top/bottom or right/left,
High-density mounting possible
Mounting position: uncritical
Weight:
0,27kg
Accessories delivered with the unit
Operating manual
Fixing clamps
Technical data
Operating KS4x-1 53
Thermocouple type Range Accuracy Resolution (
Ô)
L Fe-CuNi (DIN) -100...900°C -148...1652°F
ß 2K
0,1 K
J Fe-CuNi -100...1200°C -148...2192°F
ß 2K
0,1 K
K NiCr-Ni -100...1350°C -148...2462°F
ß 2K
0,2 K
N Nicrosil/Nisil -100...1300°C -148...2372°F
ß 2K
0,2 K
S PtRh-Pt 10% 0...1760°C 32...3200°F
ß 2K
0,2 K
R PtRh-Pt 13% 0...1760°C 32...3200°F
ß 2K
0,2 K
Table 1 Thermocouple measuring ranges
Type Sens. current Range Accuracy Resolution (
Ô)
Pt100
0,2mA
-200...100°C -140...212°F
ß 1K
0,1K
Pt100 -200...850°C -140...1562°F
ß 1K
0,1K
Pt1000 -200...850°C -140...1562°F
ß 2K
0,1K
KTY 11-6 -50...150°C -58...302°F
ß 2K
0,05K
Table 2 Resistance transducer measuring ranges
Range Input resistance Accuracy Resolution (
Ô)
0-10 Volt
~ 110 kΩ Я 0,1 % Я 0,6 mV
0-20 mA 49
Ω (voltage requirement ß 2,5 V) Я 0,1 % Я 1,5 μA
Table 3 Current and voltage measuring ranges
