If measured value monitoring + alarm status storage is chosen (
ConF / Lim /
Fnc.x = 2), the alarm relay remains switched on until the alarm is resetted in the
error list (
Lim 1..3 = 1).
3.8 Operating structure
After supply voltage switch-on, the controller starts with the operating levels.
The controller status is as before power off.
g
PArA - level:
At
PArA - level, the right decimal point of the upper
display line is lit continuously.
g
ConF - level:
At
ConF - level, the right decimal point of the upper
display line blinks
.
When safety switch Loc is open, only the levels enabled by me-
ans of BlueControl (engineering tool) are visible and accessible
by entry of the password adjusted by means of BlueControl (en-
gineering tool). Individual parameters accessible without password must be co-
pied to the extended operating level.
Factory setting:
Safety switch Loc closed: all levels accessible without
restriction, password
PASS = OFF.
Safety switch
Loc
Password entered with
BluePort®
Function disabled or enabled
with BluePort®
Access via the instrument
front panel:
closed
OFF / password
disabled / enabled
enabled
open
OFF / password
disabled
disabled
open
OFF
enabled
enabled
open
Password
enabled
enabled after password
entry
Operation
Operating structure
20
Operating KS4x-1
Щ
Щ
Щ
Щ
End
126
CAL
126
ConF
126
125
126
PArA
126
Щ
М
М
М
3 sec.
PASS
PASS
PASS
PASS
