1 with current and voltage input signals, scaling is required (see chapter 5.3)
g
Resetting the controller configuration to factory setting (Default)
r chapter 12.1 (page 56)
Configuration level
Configuration 24 Operating KS4x-1
Lim
Name Value range Description Default
Fnc.1
Fnc.2
Fnc.3
Function of limit 1/2/3 1
0 switched off
1 measured value monitoring
2 Measured value monitoring + alarm status storage. A stored
limit value can be reset via error list, Ò-key or a digital
input (
® LOGI/ Err.r).
Src.1
Src.2
Src.3
Source of limit 1/2/3 1
0 process value
1 control deviation xw (process value - set-point)
2 control deviation xw (with suppression after start-up and
set-point change)
6 effective set-point Weff
7 correcting variable y (controller output)
HC.AL
Alarm heat current function (INP2) 0
0 switched off
1 Overload short circuit monitoring
2 Break and short circuit monitoring
LP.AL
Monitoring of control loop interruption for heating 0
0 switched off / inactive
1 active
If
ti1=0 LOOP alarm is inactive!
Hour OFF..999999 Operating hours (only visible with BlueControl!) OFF
Swit OFF..999999 Output switching cycles (only visible with BlueControl!) OFF
Out.1
Name Value range Description Default
O.Act
Method of operation of output OUT1 0
0 direct / normally open
1 inverse / normally closed
Y.1
Y.2
Controller output Y1/Y2 1
0 not active
1 active
Lim.1
Lim.2
Lim.3
Limit 1/2/3 signal 0
0 not active
1 active
LP.AL
Interruption alarm signal (LOOP) 0
0 not active
1 active
HC.AL
Heat current alarm signal 0
0 not active
1 active
