Page 39: Parameter setting level

g
Resetting the controller configuration to factory setting (Default)
r chapter 12.1 (page 56)
Parameter setting level
Operating KS4x-1
39
Parameters
Name
Value range Description
Default
SP.04
-1999...9999
Segment end set-point 4
200 1
Pt.04
0...9999
Segment time 4 [min]
10 2
1 If SP.01 … SP.04 = OFF then following parameters are not shown
2 If segment end set-point = OFF then the segment time is not visible
InP.1
Name
Value range Description
Default
InL.1
-1999...9999
Input value for the lower scaling point
0
OuL.1
-1999...9999
Displayed value for the lower scaling point
0
InH.1
-1999...9999
Input value for the upper scaling point
20
OuH.1
-1999...9999
Displayed value for the lower scaling point
20
t.F1
-1999...9999
Filter time constant [s]
0,5
InP.2
Name
Value range Description
Default
InL.2
-1999...9999
Input value for the lower scaling point
0
OuL.2
-1999...9999
Displayed value for the lower scaling point
0
InH.2
-1999...9999
Input value for the upper scaling point
50
OuH.2
-1999...9999
Displayed value for the upper scaling point
50
Lim
Name
Value range Description
Default
L.1
-1999...9999
Lower limit 1
-10
H.1
-1999...9999
Upper limit 1
10
HYS.1
0...9999
Hysteresis limit 1
1
L.2
-1999...9999
Lower limit 2
OFF
H.2
-1999...9999
Upper limit 2
OFF
HYS.2
0...9999
Hysteresis limit 2
1
L.3
-1999...9999
Lower limit 3
OFF
H.3
-1999...9999
Upper limit 3
OFF
HYS.3
0...9999
Hysteresis limit 3
1
HC.A
-1999...9999
Heat current control limit [A]
50
