Configuration level
Configuration 26 Operating KS4x-1
Name Value range Description Default
HC.SC
Solid state relay (SSR) short circuit signal (only visible
when O.TYP=0)
0
0 not active
1 active
timE
Timer end signal (only visible when O.TYP=0) 0
0 not active
1 active
P.End
Programmer end signal (only visible when O.TYP=0) 0
0 not active
1 active
FAi.1
FAi.2
INP1/ INP2 error (only visible when O.TYP=0) 1
0 not active
1 active
Out.0 -1999...9999 Scaling of the analog output for 0% (0/4mA or 0/2V, only
visible when O.TYP=1..5)
0
Out.1
-1999...9999 Scaling of the analog output for 100% (20mA or 10V, only
visible when O.TYP=1..5)
100
O.Src
Signal source of the analog output OUT3 (only visible when
O.TYP=1..5)
1
0 not used
1 controller output y1 (continuous)
2 controller output y2 (continuous)
3 process value
4 effective set-point Weff
5 control deviation xw (process value - set-point)
fOut Forcing OUT3 (only visible with BlueControl!) 0
0 No forcing
1 Forcing via serial interface
g
Method of operation and usage of output
Out.1 to Out.3:
Is more than one signal chosen active as source, those signals are OR-linked.
LOGI
Name Value range Description Default
L_r
Local / Remote switching (Remote: adjusting of all values
by front keys is blocked)
0
0 no function (switch-over via interface is possible)
1 active
2 DI1
3 DI2 (only visible with OPTION)
4 DI3 (only visible with OPTION)
SP.2
Switching to second setpoint SP.2 0
0 no function (switch-over via interface is possible)
2 DI1
3 DI2 (only visible with OPTION)
4 DI3 (only visible with OPTION)
