4.4.7 KS4x-1 with measured value output

ConF / Out.3: O.tYP = 1

Out.3 0...20mA continuous

=

2

Out.3 4...20mA continuous

=

3

Out.3 0...10V continuous

=

4

Out.3 2...10V continuous

Out.0 = -1999...9999

scaling

Out.3

for 0/4mA or 0/2V

Out.1 = -1999...9999

scaling

Out.3

for 20mA or 10V

O.Src = 3

signal source for

Out.3 is

the process value

Configuration level

Configuration examples

36

Operating KS4x-1

phys.

quantity

mA / V

phys. quantity

Out.1

Out.0

0/4mA

0/2V

20mA

10V

1

2

3

4

7

5

8

6

9

10

11

12

13

14

15

L
N

}

90...250VAC
24VUC

U

OUT3

INP1

+
