Installation and operating instructions 8 BATCHFLUX
1.3 Installation requirements
Items supplied with flowmeter
•
BATCHFLUX IFM 5015 K compact
flowmeter in the version as ordered
•
Installation and operating instructions,
as agreed
•
Certificate of system calibration data
(as agreed)
Excluding fitting accessories. Stud bolts,
gaskets, etc., to be provided by customer.
All operating data and function values
are factory set according to your order
specifications.
Requirements
Use in the food industry
The IFM 5015 K is specifically suitable for use
in the food and beverage industry or similar
sterile processes.
The IFM 5015 K is steam-resistant and can be
pigged.
The measuring tube can be SIP or CIP
cleaned when in installed condition. During the
cleaning the meter(s) must be switched off to
maintain the reliability of the unit(s).
•
Operating pressure, type, and space
between pipe flanges: see Table.
•
Tighten stud bolts uniformly down to the
metal stop in diagonally opposed
sequence. See Table for type and number
of stud bolts.
•
Install meter vertically or in a slope due to
its conical in/outlet.
On DN 15 ( 1 /
2
”) and DN 32 (1 1 /
4
”), a
BATCHFLUX with straight ceramic tube is
available.
DIN 2501
ANSI B 16.5 Space between Bolts Max torque
and JIS pipe flanges Nm kpm ft × lbf
DN 2.5 1 /
10
" 51.8 mm (2.04") 4 x M12 10 1.0 7.2
DN 4 1 /
8
" 51.8 mm (2.04") 4 x M12 10 1.0 7.2
DN 6 1 /
4
" 51.8 mm (2.04") 4 x M12 10 1.0 7.2
DN 10 3 /
8
" 51.8 mm (2.04") 4 x M12 10 1.0 7.2
DN 15 1 /
2
" 51.8 mm (2.04") 4 x M12 10 1.0 7.2
DN 25 1" 58.0 mm (2.28") 4 x M12 10 1.0 7.2
DN 32 1 1 /
4
“ 83.0 mm (3.27“) 4 xM16 43 4.3 31.0
DN 40 1 1 /
2
" 83.0 mm (3.27") 4 x M16 43 4.3 31.0
