Installation and operating instructions 22 BATCHFLUX
Fct. Text Description and settings
1.6 →
VALUE P Set pulse value per unit
volume (appears only when
“PULSE/VOL.“ set under
“SELECT.P“ above)
• xxxx PulS/m3
• xxxx PulS/Liter
• xxxx PulS/US.Gal
• xxxx PulS/ user unit, factory
set is “Liter“ (see Fct. 3.5)
Setting range “xxxx“ depends
on the pulse width and the full-
scale range:
P
min
= F
min
/ Q
100%
P
max
= F
max
/ Q
100%
Press key ↵ to return to
Fct.1.6 “PULS.OUTP.P“.
→
VALUE P Set pulse value per unit time
(appears only when
“PULSE/TIME“ set under
“SELECT. P“ above)
• xxxxx PulSe/Sec (=Hz)
• xxxx PulSe/min
• xxxx PulSe/hr
• xxxx PulSe/user unit,
factory set is “hr“
(see Fct. 3.5)
Setting range “xxxx“ depends
on pulse width, see above.
Press key
↵ to return to
Fct. 1.6 “PULS.OUTP. P“.
1.7 STATUS. S Status output S
No hardware available
ALL ERROR
• FATAL ERROR
• OFF
• ON
• F/R INDIC. (F/R indication
for forward/reverse
measurement)
• TRIP.POINT
Setting range:
002 - 115 PERCENT
Press key
↵ to transfer to
number setting!
Press key
↵ to return to
Fct. 1.7 “STATUS. S“.
Fct. Text Description and settings
2.0 TEST Test menu
2.1 TEST Q Test of range Q
Precautionary query
• SURE NO
Press key
↵ to return to
Fct. 2.1 “TEST Q“.
• SURE YES
Press key
↵ and select value
with keys ↑ and ↓:
-110 / -100 / -50 / -10 / 0 / +10 /
+50 / +100 / +110 PCT.
of set measuring range
Q
100%
in each case.
Displayed value present at
outputs I and P.
Press key
↵ to return to
Fct. 2.1 “TEST Q“.
2.2 HARDW.
INFO
Hardware information and
error status
Please note down all 6 codes
before consulting factory.
→
MODUL
ADC X . X X X X X . X X
Y Y Y Y Y Y Y Y Y Y
Press key
↵ to transfer to
“MODUL I/O“.
→
MODUL
I/O X . X X X X X . X X
Y Y Y Y Y Y Y Y Y Y
Press key
↵ to transfer to
“MODUL DISP“.
→
MODUL
DISP. X . X X X X X . X X
Y Y Y Y Y Y Y Y Y Y
Press key
↵ to return to
Fct. 2.2 “HARDW. INFO“.
