Installation and operating instructions
34 BATCHFLUX
5.12 User-definable unit
Fct. 3.5 USER UNIT
Press key
→ .
→ TEXT VOL. = Set the text for user-
defined flow unit, press key
→
• Liter
(max. 5 characters, factory-set is
“Liter“) Characters assignable to
each
place: A-Z, a-z, 0-9, or
“–“ (= blank)
Change flashing place (cursor) with keys
↑
and
↓ . Shift cursor 1 place to right or left with
keys
→ and ←. Transfer to subfunction
“FACT.VOL“ with key
↵.
→ FACT. VOL. = Set factor F
M
for volume,
press key
→
• 1.00000 E+3 (factory-set is “1000“ /
Factor FM = volume per
1
m
3
) Setting range:
1.00000 E-9 to 9.99999 E+9
( = 10
-9
to 10
+9
)
Change flashing place (cursor) with keys
↑
and
↓ . Shift cursor 1 place to right or left with
keys
→ and ←. Transfer to subfunction
“TEXT TIME“ with key
↵.
→ TEXT TIME = Set text für required time,
press key
→
• hr (max. 3 places, factory-set is “hr =
hour“)
Characters
assignable to each place:
A-Z, a-z, 0-9, or “–“ (= blank)
Change flashing place (cursor) with keys
↑
and
↓ . Shift cursor 1 place to right or left with
keys
→ and ←. Transfer to subfunction
“FACT.TIME“ with key
↵.
→ FACT. TIME = Set Factor F
T
for time,
press key
→
• 3.60000 E+3 (factory-set is “3600“ /
set Factor F
T
in seconds)
Setting range:
1.00000 E-9
to 9.99999 E+9
( = 10
-9
to 10
+9
)
Change flashing place (cursor) with keys
↑
and
↓ . Shift cursor 1 place to right or left with
keys
→ and ←. Press key ↵ to return to
Fct. 3.5 USER UNIT.
Factors for volume F
M
(Factor F
M
= volume per 1 m
3
)
Volumetric unit
Text examples
Factor F
M
Setting
Cubic
metres
m
3
11 11
1.0
1.00000 E+0
Litres
Liter
1 000
1.00000 E+3
Hectolitres
h Lit
10
1.00000 E+1
Decilitres
d Lit
10 000
1.00000 E+4
Centilitres
c Lit
100 000
1.00000 E+5
Millilitres
m Lit
1 000 000
1.00000 E+6
US
gallons
USGal
22
264.172
2.64172 E+2
Millions US gallons
USMG
0.000264172
2.64172 E-4
Imperial
gallons
GBGal
22
219.969
2.19969 E+2
Mega imperial gallons
GBMG
0.000219969
2.19969 E-4
Cubic
feet
Feet3
333
35.3146
3.53146 E+1
Cubic
inches
inches3
61 024.0
6.10240 E+4
US barrels, liquid
US BaL
88 88
8.36364
8.38364 E+0
US barrels, ounces
US BaO
33 813.5
3.38135 E+4
Factors for time F
T
(Factor F
T
in seconds)
Time unit
Text examples
Factor F
T
(seconds)
Setting
Seconds
Sec
1
1.00000 E+0
Minutes
min
60
6.00000 E+1
Hours
hr
3 600
3.60000 E+3
Day
DAY
86 400
8.64000 E+4
Year (= 365 days)
YR
31 536 000
3.15360 E+7
