Installation and operating instructions 39 BATCHFLUX
7.3 Hardware information and error status, Fct. 2.2
Please note!
Do not open the housing of the
BATCHFLUX IFM 5015 K.
Danger of contamination with substances likely
to destroy the moisture barrier of the electronic
equipment (e.g. if CIP or SIP cleaned from the
outside).
Therefore, please contact your KROHNE
Service engineer before you open the housing.
Switch off power source
before opening the housing
•
Before consulting the factory about
errors/faults or flow measurement
problems, please invoke Fct. 2.2 HARDW.
INFO (hardware information).
•
An 8-character and a 10-character status
code are stored under this function in each
of 3 “windows“. These 6 status codes will
enable rapid and simple diagnosis of your
compact flowmeter.
•
Power the system.
•
Press the following keys for display of the
status codes:
Key Displayed Description
→ If “YES“ is set under Fct. 3.4 ENTRY CODE, key-in
the 9-keystroke CODE 1:
→ → → ↵ ↵ ↵ ↑ ↑ ↑
Fct. 1.0 OPERATION
↑ Fct. 2.0 TEST
→ Fct. 2.1 TEST Q
↑ Fct. 2.2 HARDW. INFO
→ → MODUL ADC -.- - - - -.- - 1st window
- - - - - - - - - Sample status code
↵ → MODUL I/O -.- - - - -.- - 2nd window 3.25105.02 ( 8-character code,
1st line)
- - - - - - - - - 3A47F01DB1 (10-character code,
2nd line)
↵ → MODUL.DISP. -.- - - - -.- - 3rd window
- - - - - - - - -
PLEASE NOTE DOWN ALL 6 STATUS CODES !
↵ Fct. 2.2 HARDW. INFO End of hardware information
(2x) 3x ↵ - - - - - - - - - - - - - / - - - Measuring mode
If you need to return your flowmeter to KROHNE, please refer to the
last-but-one page of these Instructions !
