Installation and operating instructions 46 BATCHFLUX
10.5 Dimensions and weights
in mm (inches)
DN 2.5 –15 /
1 /
10
“ – ½“
Meter size Diameter d
1
Weight
DN inches mm (inches) kg lb
2.5 1 /
10
6 (0.24) 1.6 (3.6)
4 1 /
6
7 (0.28) 1.6 (3.6)
6 1 /
4
9 (0.35) 1.6 (3.6)
10 3 /
8
12 (0.47) 1.6 (3.6)
15 1 /
2
14.3 (0.56) 1.6 (3.6)
10
option: 4 x M6 bolt hole on both sides
(section M-M)
M6
miniature
circular
connector
flow direction
series 713,
4-pin
option: ventilation
