5.6 Current output I
No HARDWARE!
Function must be set to “OFF”.
Fct. 1.5 CUR.OUTP. I (not available, no
HARDWARE !)
Press key
→ .
→ FUNCTION I = Select function for the
current output, press key
→
• OFF (switched off,
do not change setting,
no hardware available)
• 1 DIR. (1 flow direction)
• 2 DIR. (2 flow directions, F/R mode,
forward/reverse)
Select with keys ↑ and ↓.
Transfer to subfunction “RANGE I“ with key
↵. Exception: when “OFF“ selected, return to
Fct. 1.5 CUR.OUTP. I.
→ RANGE I = Select measuring range,
press key
→
• 0 - 20 mA
• 4 - 20 mA
Select with keys ↑ and ↓.
Transfer to subfunction “I ERROR“ with key
↵.
→ I ERROR = Set error value,
press key
→
• 0 mA
• 3.6 mA (only
possible when
range “4 - 20 mA“
selected)
• 22 mA
Select with keys ↑ and ↓.
Press key ↵ to return to Fct. 1.5 CUR.OUTP.
I.
Please refer to Sect. 3.2
“Factory settings“.
Refer to Sect. 2.3 for connection diagrams,
and to Sect. 5.14 for characteristics.
5.7 Pulse output P
Fct. 1.6 PULS.OUTP. P
Press key
→ .
→ FUNCTION P = Select function for the
pulse output, press key
→
• OFF (switched off, no function)
• 1 DIR. (1 flow direction)
• 2 DIR. (2 flow directions, F/R mode,
forward/reverse)
Select with keys ↑ and ↓.
Transfer to subfunction “SELECT P“ with key
↵. Exception: when “OFF“ selected, return to
Fct. 1.6 PULS.OUTP. P.
→ SELECT P = Select pulse type,
press key
→
• 100-1000 Hz
• PULSE/VOL.
(pulses per unit volume,
flow)
• PULSE/TIME (pulses per unit time
for 100 % flow)
Select with keys ↑ and ↓.
Transfer to subfunction “PULSEWIDTH“
with key
↵.
Note: when 100-1000 Hz selected,
return to Fct. 1.6 PULS.OUTP. P.
→ PULSEWIDTH = Select pulse width,
press key
→
• 50 mSec F
max
= 10 Hz
• 100 mSec F
max
= 5 Hz
• 200 mSec F
max
= 2.5 Hz
• 500 mSec F
max
= 1 Hz
for all F
min
= 0.0056 Hz
(= 20 pulses / hr)
Select with keys
↑ and ↓.
Transfer to subfunction “VALUE P“ with key ↵
or return to Fct. 1.6 PULS.OUTP. P,
depending on selected pulse type in
subfunction “SELECT P“.
