Installation and operating instructions 4 BATCHFLUX
System description
The BATCHFLUX IFM 5015 K compact electromagnetic flowmeter is a precision instrument
designed for the linear flow measurement of liquid products.
The products need to be electrically conductive:
> 5
µS/cm (except for water)
> 20 µS/cm (for water)
The full-scale range Q
100%
can be set as a function of the meter size:
DN 2.5 – 40 and 1 /
10
” – 1 1 /
2
” Q
100%
= 0.0015 - 15 l/s
This is equivalent to a flow velocity of 0.3 - 12 m/s.
Standards and approvals
•
BATCHFLUX IFM 5015 K with the IFC 015 signal converter meets the EU-EMC Directives and
bears the CE and 3A symbol.
•
The 3A approval accepts only adapters shown in Sect. 1.5.
•
All factories and production sequences are ISO 9001 certified.
Product liability and warranty
The compact BATCHFLUX IFM 5015 K electromagnetic flowmeter is designed exclusively for
measuring the volumetric flowrate of electrically conductive, liquid process products.
The compact flowmeter is not suitable for use in hazardous areas. Other flowmeter series are
available for such applications.
Responsibility as to suitability and intended use of this compact electromagnetic flowmeter rests
solely with the operator.
Improper installation and operation of the flowmeters (systems) may lead to loss of warranty.
In addition, the “General conditions of sale“ forming the basis of the purchase contract are
applicable.
If BATCHFLUX IFM 5015 K flowmeters need to be returned to KROHNE, please note the
information given on the last-but-one page of these instructions. KROHNE regret that they cannot
repair or check your flowmeter(s) unless these are accompanied by the completed form sheet.
