Installation and operating instructions 31 BATCHFLUX
→ VALUE P = Set pulse value per unit volume,
(appears only when “PULSE/VOL.“ has been set under “SELECT P“) press key
→
• XXXX PulS/m 3
• XXXX PulS/Liter
• XXXX PulS/US.Gal
• XXXX PulS/ user-defined unit,
factory-set is “Liter“, see Sect. 5.12.
Select with keys
↑ and ↓.
Transfer to number setting with key →, 1st digit (cursor) flashes.
Set numerical value
• XXXX (Setting range depends on
pulse width and full-scale range:
P
min
= F
min
/ Q
100%
P
max
= F
max
/ Q
100%
)
Change flashing digit (cursor) with keys
↑ and ↓ ,
Shift cursor 1 place to right or left with keys → und ← .
Press key ↵ to return to Fct. 1.6 PULS.OUTP. P.
or
→ VALUE P = Set pulse value per unit time,
(appears only when “PULSE/TIME“ has been set under “SELECT P“), press key
→
• XXXXX PulSe/Sec (max. 10 kHz)
• XXXX PulSe/min
• XXXX PulSe/hr
• XXXX PulSe/ user-defined unit,
factory-set is “hr“, see Sect. 5.12.
Select with keys
↑ and ↓.
Transfer to number setting with key →, 1st digit (cursor) flashes.
Set numerical value
• XXXX
(Setting range depends on
pulse width)
Change flashing digit (cursor) with keys
↑ and ↓ ,
Shift cursor 1 place to right or left with keys → and ←.
Press key ↵ to return to Fct. 1.6 PULS.OUTP. P.
Please refer to Sect. 3.2
“Factory settings“
Refer to Sect. 2.3 for connection diagrams,
and to Sect. 5.14 for characteristics.
