KROHNE ALTOFLUX 2W IFM 4042K EN User Manual
Page 3
02/2001
ALTOFLUX 2W
3
&RQWHQWV
•
Your operatig data
2
•
System description
4
•
Product liability and warranty
4
•
CE / EMC / Standards / Approvals
4
•
Software history
4
7HLO$ ,QVWDOODWLRQDQG6WDUWXS
1
Installation
5 - 10
1.1
Items included with supply
5
1.2
Handling
5
1.3
Installation location
6
1.4
Suggestions for installation
7
1,5
Installation in the pipeline
8
1.6
Torques
9
1.7
Grounding
10
2
Electrical connection
11 – 16
2.1
Information on electrical connection and connection data
11
2.2
Output circuit diagrams
12 – 13
2.3
Characteristic of the outputs
14 – 16
3
Start-up
17
3.1
Power ON and measurement
17
3.2
Factory settings
17
7HLO% ,)&6LJQDOFRQYHUWHU
²
4
Operation of the signal converter
18 - 33
4.1
KROHNE operator control concept
18
4.2
Operating and check elements
19
4.3
Function of keys
20 – 21
4.4
Table of settable function
22 – 32
4.5
Error messages in measuring mode
33
4.6
Reset counter and cancel error messages
33
7HLO& 7HFKQLFDO'DWD%ORFNGLDJUDPXQG0HDVXULQJSULQFLSOH
²
5
Technical Data
34 - 40
5.1
Full-scale ranges
34
5.2
Error limits at reference conditions
35
5.3
IFC 040 Signal converter
36 – 37
5.4
IFS 4002 Primary head
38
5.5
Dimensions and weights
39
5.6
Limits
40
6
Block diagram of signal converter
41
7
Measuring principle
42
8
If you need to return flowmeters for testing or repair to KROHNE
43
