KROHNE ALTOFLUX 2W IFM 4042K EN User Manual
Installation and operating instructions, Electromagnetic flowmeters, How to use these instructions
Installation and
operating instructions
ALTOFLUX 2W
IFM 4042 K
Electromagnetic flowmeters
Variable area flowmeters
Vortex flowmeters
Flow controllers
Electromagnetic flowmeters
Ultrasonic flowmeters
Mass flowmeters
Level measuring instruments
Communications engineering
Engineering systems & solutions
Applicable to
Software Versions
● Display/Control unit
No. 3.19019.xx00
● ADC module
No. 3.19749.xx00
● I/O module
No. 3.18748.xx00
DIN A4: 7.10004.31.00
©
KROHNE 02/2001
US size: 7.10004.71.00
GR/OP
How to use these Instructions
The flowmeters are supplied ready for operation.
–
Installation in the pipeline (Section 1)
Pages 5-10
–
Electrical connection (Section 2)
Pages 11-13
–
Start-up (Section 3)
Page
17
Power the flowmeter. THAT’S ALL. The system is operative.
