Sensor data - setting of sensor type
Designation Settings Description
Slope xxx.x %
0.00 – 100 % Displays the dynamic sensor slope. The value changes depending on the calibration
data and sensor duration of operation.
Manual correction of the value is generally not necessary.
Please ask for details at the KROHNE service department covering your area.
Offset +- x.xx pX
- 9.99 - + 9.99
pX Displays the dynamic sensor zero point. The value changes depending on the
calibration and sensor duration of operation.
Manual correction of the value is generally not necessary.
Please ask for details at the KROHNE service department covering your area.
Electrode Gas sensor
pH-Type
Ammoniac
Ammonium
Nitrate
Potassium
Calcium
Sulfite
Cyanide
Chloride
Fluoride
Sodium
Bromide
Nitrite
Redox
Oxygen
Chlorine
Phosphate
Lithium
Refraction
Lead
Sulfide
Sulfide-H
Sulfide-H2 Sensor type that is recognised by the converter.
The new sensor type must be selected here if the sensor is changed on the respective
measuring channel.
Depending on sensor type the corresponding factory setting is retrieved with the
specific sensor data.
Further sensor types on request.
Zero line 000.0 ppm Lower sensor-specific sensitivity threshold. This value is a component of the factory
calibration. Modifications only after consultation with KROHNE-System service
department.
Sensor calibration
Designation Settings Description
Current value 00.00 ppm Displays the last current calibration value.
Entry of the offset value for offset calibration here. See also offset calibration
Cal. method Offset
2-point
StdAdd.
C-curve Opportunity to select calibration routines. See calibration menu for further details.
Offset
1-point adaptation of an available calibration curve in order to compensate for drift
deviations.
2-point
Calibration method via 2 standard solutions.
Std.Add.
Calibration routine via a standard addition (optional).
C-curve
Calibration by creating a concentration curve (optional).
