KROHNE OPTISENS PAM 2080 EN - Manual (Page 20)

www.krohne.com 20
5.4 Control button functions
Some of the control buttons have multiple functions,
depending on which area of the operating menu you are currently in .
Button Functions in measuring mode Functions in parameter mode
Retrieval of parameter menus in the respective
measuring channel or data logger area.
Back to measuring mode.
Cancel entries.
Page down individual channels
- Channel 1
- Channel 2
- Channel 3 ..... etc.
- Trendline 1
- Trendline 2
Acknowledge entries and jump to
the next point / menu address.
Set system status to “Maintenance”.
Display:
(Signal outputs on Hold.
Automatic rinse function is off.)
Jump up one address in the menu
field. Increase values on entry.
Set system status to “Measurement”.
(Signal outputs are released. Automatic rinse
function is active.)
Jump down one address in the
menu field. Reduce value on entry.
Calibration functions are launched.
Display:
(Signal outputs are frozen according to the set
Hold time.)
Trigger rinse function manually.
Display:
(Signal outputs are frozen according to the set
Hold time.)
