Switching contact
Relay No. 3
00 – 16
Pre-alert
00 = not active
01 = active on measuring channel 1
02 = active on measuring channel 2
03 = active on measuring channel 3
and so on
Alert Setting possibilities as with pre-alert
Fault Setting possibilities as with pre-alert
Switching contact
Relay No. 4
00 – 16
Pre-alert
00 = not active
01 = active on measuring channel 1
02 = active on measuring channel 2
03 = active on measuring channel 3
and so on
Alert Setting possibilities as with pre-alert
Fault Setting possibilities as with pre-alert
Switching contact
Relay No. 5
00 – 16
Pre-alert
00 = not active
01 = active on measuring channel 1
02 = active on measuring channel 2
03 = active on measuring channel 3
and so on
Alert Setting possibilities as with pre-alert
Fault Setting possibilities as with pre-alert
The relays can be freely programmed individually or in combinations. In the process only one alert status
can be allocated to each relay (lower alert threshold or upper alert threshold or technical fault). Incorrect
or duplicated allocations can lead to measuring converter malfunction.
