Terminal occupancy
Terminal Function
L ~ Auxiliary power 230 V AC
N ~ Auxiliary power 230 V AC
1
2
K1 Relay 1 max. 230 V AC, 2A
3
4
K2 Relay 2 max. 230 V AC, 2A
5
6
K3 Relay 3 max. 230 V AC, 2A
7
8
K4 Relay 4 max. 230 V AC, 2A
9
10
K5 Relay 5 max. 230 V AC, 2A
21 +
22 -
Analogue output 1 0/4 .. 20 mA
23 +
24 -
Analogue output 2 0/4 .. 20 mA
25 +
26 -
Analogue output 3 0/4 .. 20 mA
27 +
28 -
Analogue output 4 0/4 .. 20 mA
PE Protective conductor (earth/ground)
PE Protective conductor (earth/ground)
