6.4 General settings
Enter the menu-button to make the general settings.
General Data
Designation Settings Description
Scroll time
00.0 – 99.9 min
Automatic display-switching between measuring channels.
00.0 min = no scroll function
Modifications
permitted
blocked
save data
load data
Permitted: Entries and modifications are possible.
Blocked: Entries and modifications are not possible.
save data: Saves the current general settings in EEPROM.
load data: Loads and uses the last saved settings
Parameters
Normal
Hold
Reset
Default
Normal
Standard setting. Relay contacts are active as long as thresholds
are exceeded.
Hold
Relay contacts are active, but are held even if thresholds are no
longer exceeded.
Reset using the Measure button.
Reset The converter carries out a new system start.
All set data are retained
Default The converter carries out a new system start. All data set by the
user are reset to factory settings.
Relay-Output
Designation Settings Description
Inverted
00000 -
11111 The switching contacts for the respective relay can be set as follows
0 = close actively (idle current, relay open as normal)
1 = open actively (operating current, relay closed as normal)
Relay allocation:
0 0 0 0 0
Relay 1
Relay2
Relay 3
Relay 4
Relay 5
Switching contacts
Relay No. 1
00 – 16 Pre-alert 00 = not active
01 = active on measuring channel 1
02 = active on measuring channel 2
03 = active on measuring channel 3
and so on
Alert Setting possibilities as with pre-alert
Fault Setting possibilities as with pre-alert
Switching contacts
Relay No. 2
00 – 16 Pre-alert 00 = not active
01 = active on measuring channel 1
02 = active on measuring channel 2
03 = active on measuring 3
and so on
Alert Setting possibilities as with pre-alert
Fault Setting possibilities as with pre-alert
