7

TECHNICAL DATA

66

OPTITEMP TRA/TCA PLUS

www.krohne.com

01/2012 - 4000630301 - MA OPTITEMP TRA/TCA Plus R01

7.6 Measuring range and permitted load

Temperatures that can be measured with an industrial thermometer depend largely on the load
of the thermometer. Load limits are defined through a variety of factors (see the subsection
"Load limits" in the "Installation" section). For this reason, the manufacturer cannot make any
universally valid statements about the measuring range and permissible load.

7.6.1 Operating limits for multipart, welded thermowells

TRA/TCA-TS32, -TF33 and -TS35 with Ø 12 x 2.5 mm / 0.47 x 0.10"

DANGER!
To prevent fatal injuries or damage, never operate the thermometer outside of its permissible
mechanical, thermal or chemical limits. For further information refer to the rest of this section
and the "Technical data" section.

DANGER!
The information in this subsection is informative only and does not reflect the vibration load
caused by flow-induced eddy shedding and the resulting vibration. If necessary, prior to
purchasing and installing an industrial thermometerfor advanced requirements, have a specific
strength calculation performed (e. g. as per DITTRICH or MURDOCK, ASME PTC 19,3TW-2010).
For further information contact the manufacturer.

CAUTION!
To prevent destruction or damage, only operate a thermometer without a thermowell in the
range of 0.8...1.2 bara / 11.6...17.4 psia.

INFORMATION!
The manufacturer can provide an optional strength calculation for a fee.

INFORMATION!
The thermowell operating limits specified below refer to a flow of air of 40 m/s or 131.2 ft/s or a
flow of water or vapour of 5 m/s or 16.4 ft/s.

Process connection

Material

Insertion length p

max

at +20°C / +400°C or

+68°F / +752°F, air

p

max

at +20°C / +400°C or

+68°F / +752°F, water /

vapour

[mm]

["]

[bar]

[psi]

[bar]

[psi]

Thread G½", G¾",
½

" NPT, ¾" NPT

1.4571 /

316 Ti

82

3.2

100 / 100

1450 / 1450

100 / 100

1450 / 1450

382

15.0

14.1 / 17.9

204 / 259

33.7 / 100

488 / 1450

Flanges ASME 1",

1½", 2" 150 lb

110

4.3

19.0 / 6.5

276 / 94

19.0 / 6.5

276 / 94

410

16.1

12.3 / 15.6

179 / 94

3.4 / 6.5

49 / 94

Flanges ASME 1",

1½", 2" 300 lb

110

4.3

49.6 / 29.4

719 / 426

49.6 / 29.4

719 / 426

410

16.1

12.3 / 15.6

179 / 226

3.4 / 29.4

49 / 426

Flanges ASME 1",

1½", 2" 600 lb

110

4.3

99.3 / 58.9

1440 / 854

99.3 / 58.9

1440 / 854

410

16.1

12.3 / 15.6

179 / 226

3.4 / 58.9

49 / 854

Flanges DN25, DN50

PN40

160

6.3

40.0 / 31.2

580 / 452

40.0 / 31.2

580 / 452
