TECHNICAL DATA
7
59
OPTITEMP TRA/TCA PLUS
www.krohne.com 01/2012 - 4000630301 - MA OPTITEMP TRA/TCA Plus R01
Figure 7-10: Weld-in thermometer according to DIN 43772 and ASME
1 TRA/TCA-T30 (conical thermowell with internal thread, one-piece, bar stock)
2 TRA/TCA-TW58 (straight thermowell with internal thread, one-piece, bar stock)
3 TRA/TCA-TW59 (conical thermowell with internal thread, one-piece, bar stock)
TRA/TCA-T30 (similar to Form 4)
DIN-Neck tube length "a" Thermowell length
"c"
Cone length "d" Measuring insert
length
[mm] ["] [mm] ["] [mm] ["] [mm] ["]
165 6.5 140 5.5 65 2.6 315 12.4
200 7.9 65 2.6 375 14.8
200 7.9 125 4.9 375 14.8
260 10.2 125 4.9 435 17.1
TRA/TCA-TW58 and -TW59
ASME-Neck tube length
"a" Insertion length "c" Thermowell length
"b" Measuring insert
length
[mm] ["] [mm] ["] [mm] ["] [mm] ["]
76 3 100 3.9 145 5.7 243 9.6
150 5.9 195 7.7 293 11.5
200 7.9 245 9.6 343 13.5
250 9.8 295 11.6 393 15.5
300 11.8 345 13.6 443 17.4
350 13.8 395 15.6 493 19.4
TRA/TCA-TW58 and -TW59
ASME-Neck tube length
"a" Thermowell length
"c" Thermowell length
"c" Measuring insert
length
[mm] ["] [mm] ["] [mm] ["] [mm] ["]
152 6 100 3.9 145 5.7 319 12.6
150 5.9 195 7.7 369 14.5
200 7.9 245 9.6 419 16.5
250 9.8 295 11.6 469 18.5
300 11.8 345 13.6 519 20.4
350 13.8 395 15.6 569 22.4
