Electrical connections – KROHNE OPTISONIC 6300 Quickstart EN User Manual
Page 21
ELECTRICAL CONNECTIONS
2
21
OPTISONIC 6300
www.krohne.com
07/2009 - 7.30959.24.00 - QS OPTISONIC 6300 R04 en
Figure 2-5: Connections in cable box (large version)
1 Connect the blue cable to the UP rail.
2 Connect the green cable to the DOWN rail.
3 Make connections in cable box.
4 Cable to converter
5 Turn the screws clockwise to secure the caps.
.book Page 21 Wednesday, August 19, 2009 8:37 AM
