Mounting the cover
Mounting the cover
Mounting the cover
Mounting the cover
1.8.2 Installation instructions for small and medium version
INFORMATION!
Not applicable for stainless steel / XT versions. These are delivered without cover.
Figure 1-10: Procedure for installation of small or medium version
1 Rail, small version
2 Rail, medium version
3 Choose for V-mode or ...
4 Choose for W-mode
5 Make settings in converter
