3.10.4.6 DATA SEPARATOR
Data must be separated from the last keyword by a space (e.g., SOUR:VOLT:LEV 100 or
LOCK OFF).
3.10.4.7 MESSAGE UNIT SEPARATOR
When two or more message units are combined in a program message, they must be separated
by a semicolon (;) (e.g., VOLT 100;MEAS:VOLT?).
FIGURE 3-4. TREE DIAGRAM OF SCPI COMMANDS USED WITH SERIES EL ELECTRONIC LOAD
LOCK subsystem
LOCK
SENSe subsystem
SENS
:CURR
:RANG
:RANG?
:VOLT
:RANG
:RANG?
STATus subsystem
STAT
:CHAN?
:COND?
:ENAB
:ENAB?
[:EVEN]?
:CSUM?
:ENAB
:ENAB?
[:EVEN]?
:OPER
:COND?
:ENAB
:ENAB?
[:EVEN]?
:NTR
:PTR
:QUES
:COND?
:ENAB
:ENAB?
[:EVEN]?
DEBug subsystem
DEB
:TREE
:DISP
:SEP
:SEP?
ROOT : (colon)
POW
[:LEV]
[:IMM]
[:AMPL]
[:AMPL?]
:MODE
:MODE?
:PROT
:PROT?
:STAT
:STAT?
:PROT[:LEV]?
:RANG
:RANG?
RES
[:LEV]
[:IMM]
[:AMPL]
[:AMPL?]
:MODE
:MODE?
:RANG
:RANG?
VOLT
[:LEV]
[:IMM]
[:AMPL]
[:AMPL?]
:PROT
[:LEV]
:OVE
STAT
STAT?
:OVE?
:UND
STAT
STAT?
:UND?
:PROT[:LEV]?
:RANG
:RANG?
[SOURce:] subsystem
[SOUR:]
INP
:PROT
:CLE
INP?
OUTP
:PROT
:CLE
OUTP?
MEAS
:ALL
:ALL2
:CURR
:POW
:VOLT
COND
[:LEV]
[:IMM]
[:AMPL]
[:AMPL?]
:MODE
:MODE?
:RANG
:RANG?
CURR
[:LEV]
[:IMM]
[:AMPL]
[:AMPL?]
:MODE
:MODE?
:PROT[:LEV]
:STAT
:STAT?
:PROT[:LEV]?
:RANG
:RANG?
FUNC
FUNC?
MODE
MODE?
SYSTem subsystem
DAMP
DAMP?
ERR?
EXT
EXT?
FAN
FAN?
PFM
PFM?
:LIST?
:STAT?
RANG
:CURR
:CURR?
:POW
:POW?
:VOLT
:VOLT?
REP
REP?
SERN?
SET?
VERS?
Calibration subsystem
CAL
:IPAD
:IPAD?
:SUBN
:SUBN?
:GATE
:GATE?
:DNS
:DNS?
