3.13 OPERATOR MAINTENANCE
No scheduled maintenance is required, other than to keep the high current connections tight
and to ensure all airways are clear of obstructions that could cause the load to overheat during
operation at higher power. Calibration Verification should be performed yearly or as required.
The exterior of the load should be cleaned periodically, as is necessary, using a soft cloth damp-
ened with a mild, non-abrasive, water-soluble detergent, and then rinsed with a water-damp-
ened soft cloth.
TABLE 3-4. ANALOG PROGRAMMING CONTROL VOLTAGE SCALE
MODE
RANGE
(SEE NOTE)
ANALOG CONTROL
Constant Current (CI) Not Applicable 60 Amperes/Volt
Constant
Power
(CP)
100 Volts 6 KWatts/Volt
200 Volts 12 KWatts/Volt
400 Volts 24 KWatts/Volt
800 Volts 48 KWatts/Volt
Constant
Voltage
(CV)
100 Volts 10 Volts/Volt
200 Volts 20 Volts/Volt
400 Volts 40 Volts/Volt
800 Volts 80 Volts/Volt
NOTE: Default voltage measurement setting for CP and CV mode is auto-
range. Use SCPI commands to change ranges (see APPENDIX B).
