1-6

SERIES EL 070110

1.7

EQUIPMENT SUPPLIED

Equipment supplied with the unit is listed in Table 1-3.

1.8

ACCESSORIES

Accessories for the Series EL Electronic Load are listed in Table 1-5.

1.9

OPTIONS

The G option (suffix G added to model number) includes the GPIB and Ethernet (LAN) inter-
faces.

1.10

SAFETY

There no

operator serviceable parts inside the case. Service must be referred to authorized per-

sonnel. Using the load in a manner not specified by Kepco, Inc. may impair the protection pro-
vided by the load. Observe all safety precautions noted throughout this manual. Table 1-6 lists
symbols used on the electronic load or in this manual where applicable.

TABLE 1-4. EQUIPMENT SUPPLIED

ITEM

PART NUMBER

QUANTITY

Source Power cable

118-1234

(Unicable 3850-761-BB/G)

1

Series EL Quick Start Guide *

228-1687

1

EL Series (except Dual models) ±LOAD terminal hardware

Screw, Cap, Hex, Silicon bronze, 3/8-16 (coarse thread) x 1 in.
Nut, Hex, silicon bronze, 3/8-16
Washer, split, silicon bronze, 3/8
Washer, flat, silicon bronze, 3/8

EL Series Dual models ±LOAD terminal hardware

Screw, Cap, Hex, Silicon bronze, 5/16-18 (coarse thread) x 1 in.
Nut, Hex, silicon bronze, 5/16-18 (Dual load only)
Washer, split, silicon bronze, 5/16 (Dual load only)
Washer, flat, silicon bronze, 5/16 (Dual load only)

101-0507
102-0182
103-0196
103-0197

101-0065

102-0011

103-0005
103-0212

2
2
2
4

4
4
4
8

Ground stud hardware

Wingnut, 1/4-20, 18-8 stainless-steel
Washer, Flat, 1/4 in., 18-8 stainless-steel
Washer, split, 1/4 in., 18-8 stainless-steel
Nut, 1/4-20, 18-8 stainless-steel

102-0190
103-0201
103-0204
102-0188

1
2
1
1

Fuse 3A, SB

141-0129

(Littelfuse 0313003.HXP)

1

* Series EL USB Driver Manual and Series EL Operator Manual are available for free download from the Kepco website
at www.kepcopower.com/support/opmanls.htm#e
Series EL Drivers are available for free download at www.kepcopower.com/drivers/drivers-dl3.htm#el
