SERIES EL 070110

1-5

1.6

SPECIFICATIONS

Parameters unique to different models of Series EL loads are listed in Table 1-1. Specifications
common to all Series EL models are listed in Table 1-2.

TABLE 1-2. SERIES EL SPECIFICATIONS

SPECIFICATION

RATING/DESCRIPTION

CONDITION/COMMENT

MODE CHARACTERISTICS

Linearity vs. programming command

See Table 1-3

5 – 100% of Full Scale

Regulation(1)

See Table 1-3

Resolution (via computer control)

14 Bits

Current readback
(Current mode)

Computer Accuracy:

±0.25%

Computer Resolution:

±15 Bits

Parameter readback
(Current and Voltage)

Accuracy:

±0.25%

Resolution:

±15 Bits

Temperature coefficient:

100 ppm/°C

CONTROL CHARACTERISTICS

USB Interface

Uses IEEE 488.2 and SCPI com-

mands and queries.

Requires driver.

RS 232 Interface

Uses IEEE 488.2 and SCPI com-

mands and queries.

Baud rate: 38400
Parity: None
Data Bits: 8
Stop Bits: 1
Flow Control: None

GPIB Interface

Uses IEEE 488.2 and SCPI com-

mands and queries.

GPIB address 10 = default

Ethernet Interface

Uses IEEE 488.2 and SCPI com-

mands and queries.

Optional

GENERAL CHARACTERISTICS

a-c Line Power Input

120 VAC ±10%, 50/60 Hz or

240 VAC ±10%, 50/60 Hz

120V is factory default; 240V requires
internal configuration (see PAR 2.3.1?)

Operating Temperature

0°C to 40°C

Dimensions (load)

19”W x 7”H x 24.5”D

See Figure 2-10.

Weight (load)

88 lbs.

Storage Requirements

–20 to +60°C, 15 to 80% RH

Relatively dust free environment

NOTE:
(1) Regulation specified after 15 minutes of operation at set power level.

TABLE 1-3. MODE CHARACTERISTICS

MODE

Linearity Vs. Programming Command

Regulation (1)

Constant Current

±0.25%

±0.25%

Constant Power

±2%

±1%

Constant Voltage

±0.25%

±0.25%

Constant Resistance

±1%

±1%

Constant Conductance

±1%

±1%

(1) Regulation specified after 15 minutes of operation at set power level
