TABLE 1-5. ACCESSORIES

ITEM

FUNCTION

KEPCO

PART NUMBER

RJ 22 Master/Slave cable, 1 ft.
(See Note.)

Daisy chains Series EL loads with the same voltage for
parallel configurations.

118-1245

Fuse 1.5A, SB

Required for units configured to run from 240V a-c
source power.

141-0031

(LittelFuse

31301.5)

Slides

Allows the unit to slide out of a rack.

108-0474

Side Support bracket

Pair required. Used to provide side support for EL
Load. Requires rear rail at 18-13/16 in. setback.

128-1775

NOTE: For units that use slide mounting, consult Kepco for longer cable lengths.

TABLE 1-6. SAFETY SYMBOLS

SYMBOL

MEANING

CAUTION: RISK OF ELECTRIC SHOCK.

CAUTION: REFER TO REFERENCED PROCEDURE.

WARNING

INDICATES THE POSSIBILITY OF BODILY INJURY OR DEATH.

CAUTION

INDICATES THE POSSIBILITY OF EQUIPMENT DAMAGE.
