1 warm-up time, Warm-up time – In-Situ Aqua TROLL 400 Modbus and SDI-12 Reference Guide User Manual
Page 44

Register
Size
(registers)
Mode & Access Level
(R/W)
Data
Type
Description
1014
3
R1/W2
time
Next user calibration
(0 = none required)
1017
1
R1
ushort Warm-up time in milliseconds = 800
1018
1
R1
ushort Fast sample rate = 800 milliseconds
1019
1
R1
ushort Number of sensor parameters (N) = 3
1020
1
R1/W3
ushort Alarm/warning parameter number
(1 – N, default = 1)
1021
1
R1/W3
16 bits Alarm and warning enable bits
(default = 0)
Bit 0 = High alarm enabled
Bit 1 = High warning enabled
Bit 2 = Low warning enabled
Bit 3 = Low alarm enabled
Bit 4 = Sensor calibration warning
1022
2
R1/W3
float
High alarm set value (default = 0.0)
1024
2
R1/W3
float
High alarm clear value (default = 0.0)
1026
2
R1/W3
float
High warning set value (default = 0.0)
1028
2
R1/W3
float
High warning clear value
(default = 0.0)
1030
2
R1/W3
float
Low warning clear value
(default = 0.0)
1032
2
R1/W3
float
Low warning set value (default = 0.0)
1034
2
R1/W3
float
Low alarm clear value (default = 0.0)
1036
2
R1/W3
float
Low alarm set value (default = 0.0)
6.1.1 Warm-up Time
If automatic density correction is disabled, this register returns the level sensor warm-up time as
shown. If automatic density correction is enabled, this register returns the sum of the level
sensor and conductivity sensor warm-up times.
