Register

Size

(registers)

Mode & Access Level

(R/W)

Data

Type

Description

0048

1

R1

ushort

Parameter ID = 1

0049

1

R1/W2

ushort

Units ID

1 =

°C (default)

2 =

°F

0050

1

R1

ushort

Data Quality ID

0051

2

R1/W3

float

Off line sentinel value (default = 0.0)

0053

1

R1

16 bits

Available Units = 0x0003 (3)

Dissolved Oxygen %Saturation

The saturation parameter is calculated from dissolved oxygen concentration and settings contained in

the sensor calibration registers.

If the parameter value is read when the sensor cap is not installed, the register returns the sentinel value

and a Data Quality ID of 7 (sensor communication error).

0054

2

R1

float

Measured value

0056

1

R1/W2

ushort

Parameter ID = 21

0057

1

R1/W2

ushort

Units ID

177 = percent saturation (default)

0058

1

R1

ushort

Data Quality ID

0059

2

R1/W3

float

Off line sentinel value (default = 0.0)

0061

1

R1

16 bits

Available Units = 0x0001 (1)

Oxygen Partial Pressure

Oxygen partial pressure is calculated using calibration information stored in the sensor cap.

If the parameter value is read when the sensor cap is not installed, the register returns the sentinel value

and a Data Quality ID of 7 (sensor communication error).

0062

2

R1

float

Measured value

0064

1

R1

ushort

Parameter ID = 30

(oxygen partial pressure)

0065

1

R1/W2

ushort

Units ID

26 = torr (default)

31
