GOS-6200 OSCILLOSCOPE
USER MANUAL
⎯ v ⎯
EC Declaration of Conformity
We
GOOD WILL INSTRUMENT CO., LTD.
No. 7-1, Jhongsing Rd., Tucheng City, Taipei County 236, Taiwan
GOOD WILL INSTRUMENT (SUZHOU) CO., LTD.
No.69 Lushan Road, Suzhou New District Jiangsu, China.
declares that the below mentioned product
GOS-6200
is herewith confirmed to comply with the requirements set out in the Council Directive
on the Approximation of the Law of Member States relating to Electromagnetic
Compatibility (89/336/EEC, 92/31/EEC, 93/68/EEC) and Low Voltage Equipment
Directive (73/23/EEC, 93/68/EEC).
For the evaluation regarding the Electromagnetic Compatibility and Low Voltage
Equipment Directive, the following standards were applied:
EN 61326-1: Electrical equipment for measurement, control and laboratory use ––
EMC requirements (1997+A1: 1998)
Conducted and Radiated Emissions
EN 55011 class B: 1998 Electrostatic Discharge
EN 61000-4-2: 1995
Current Harmonic
EN 61000-3-2: 1995 Radiated Immunity
EN 61000-4-3: 1996
Voltage Fluctuation
EN 61000-3-3: 1995 Electrical Fast Transients
EN 61000-4-4: 1995
————————————————
Surge Immunity
EN 61000-4-5: 1995
————————————————
Conducted Susceptibility
EN 61000-4-6: 1996
————————————————
Power Frequency Magnetic field
EN 61000-4-8: 1993
————————————————
Voltage Dips/ Interrupts
EN 61000-4-11: 1994
Low Voltage Equipment Directive 73/23/EEC & amended by 93/68/EEC
Safety Requirements
IEC/EN 61010-1: 2001
GOS-6200 OSCILLOSCOPE
USER MANUAL
⎯ 1 ⎯
1.PRODUCT INTRODUCTION
1-1. Description
The GOS-6200 is a 200MHz, two-channel, dual-sweep, portable oscilloscope
for general purpose use. A microprocessor-based operating system controls
most of the functions of the instrument, including cursor readout and
digitized panel setting. On-screen alphanumeric readout and cursor function
for voltage, time, frequency and phase measurement provide extraordinary
operational convenience. It also has the function of TV Line select for
triggering setting, auto measurement for frequency, period, pulse width and
duty cycle and auto setting function. Ten different user defined instrument
settings can be saved and recalled without restriction.
The vertical deflection system has two input channels. Each channel has 11
basic deflection factors from 2mV to 5V per division. The horizontal
deflection system provides single, dual or delayed sweeps from 0.5s to 20ns
per division (delayed sweep, 50ms to 20ns per division). The trigger system
provides stable triggering over the full bandwidth of the vertical deflection
system.
