p. 8 GFG-3015
Sweep Mode Linear or Log sweep
Sweep Range
150kHz~15MHz
15kHz~1.5MHz
1.5kHz~150kHz
150Hz~15kHz
15Hz~1.5kHz
1.5Hz~150Hz
0.15Hz~15Hz
0.01Hz~1.5Hz
Width >100:1(In Same Frequency Range)
Rate 0.01Hz~10kHz
Symmetry Control 90:10:90 ; Resolution:1%
Sweep
Sweep output 0 to≥-5Vp-p into 10k Ω
Types
AM, FM, Sweep, Trigger(int/ext), Gate or
Burst (Implement by Trigger Type)
Waveform
Sine, Square, Triangle, Ramp or
Variable Symmetry Pulse
Rate Frequency
Range
10mHz~10KHz in 3 Frequency Range
(auto switch)
Rate Frequency
Accuracy
5%±1 count
Rate Frequency
Resolution
10.0kHz~0.1kHz(100Hz)
99Hz~1Hz(1Hz)
0.99Hz~0.01Hz(0.01Hz)
Symmetry 90%:10%:90%; Resolution:1%
Symmetry Accuracy ±1 count( ≤1%)
Output Level ≧ 1Vpp into 10kΩ load
Sine Wave Distortion ≤2% from 10Hz to 10kHz
Amplitude
Modulation
Depth 0~100%
Modulation
Frequency Rate
0.01Hz ~ 10kHz(INT) DC~1MHz(EXT)
Carries -3dB
Bandwidth
<100Hz to >5MHz
External Sensitivity ≤10Vpp for 100% modulation
Frequency Modulation
Deviation 0~±15%
Modulation
Frequency Rate
0.01Hz ~ 10kHz(INT) DC ~ 50kHz(EXT)
Modulation
External Sensitivity ≤5Vpp for 15% deviation
