GSP-930 Quick Start Guide
52
Power for Option
Connector Type SMB male
Voltage/Current DC +7V / 500 mA max With short-circuit
protection
USB Host
Connector Type A plug
Protocol Version 2.0 Supports
Full/High/Low speed
MicroSD Socket
Protocol SD 1.1
Supported Cards microSD, microSDHC Up to 32GB capacity
Rear Panel Input/Output
Reference Output
Connector Type BNC female
Output Frequency 10 MHz
Output
Amplitude 3.3V CMOS
Output
Impedance 50 ohm
Reference Input
Connector Type BNC female
Input Reference
Frequency 10 MHz
Input Amplitude -5 dBm to +10 dBm
Frequency Lock
Range Within ± 5 ppm of the
input reference frequency
Alarm Output
Connector Type BNC female; Open-
collector
Trigger Input/ Gated Sweep Input
Connector Type BNC female
Input Amplitude 3.3V CMOS
Switch Auto selection by function
LAN TCP/IP Interface
Connector Type RJ-45
Base 10Base-T; 100Base-Tx; Auto-MDIX
USB Device
Connector Type B plug For remote control
only; supports USB
TMC
Protocol Version 2.0 Supports Full/High
speed
