APPENDIX
45
GSP-930 Default Settings
The following default settings are the factory configuration settings
for the spectrum analyzer (Function settings/Test settings).
Frequency
Center Frequency: 1.5GHz Start Frequency: 0Hz
Stop Frequency: 3GHz CF Step: Auto
Frequency Offset: 0Hz
Span
Span: 3GHz
Amplitude
Reference level: 0.00dBm Attenuation: Auto
Scale Div: 10 Scale Type: Log
Scale: Off Y Axis: dBm
Reference level offset:
0.00dBm
Correction: Off
Input Z: 50Ω Input Z calibration: 0.000dB
Preamp: Bypass
Autoset
Amp.Floor: Auto Span: Auto
BW/Avg
RBW: Auto VBW: Auto
VBW/RBW: N/A Average: Off
Average Power: Log Power EMI Filter: Off
Sweep
Sweep Time: Auto Sweep: Continuous
Gated Sweep: Off Gate Delay: 50ms
Gate Length: 540ms
Trace
Activated traces: trace 1 Trace Type: Clear and Write
Trace Math: Off Detection: Auto, Normal
Display
Window Setup: Spectrum LCD Brightness: Hi
LCD Backlight: On Display Line, -50.0dBm, Off
