P/N 3100179 ISSUE 1 PAGE 4
DeviceNet Object Class Services:
SERVICE SERVICE CODE PARAMETERS
Get Attribute Single 0x0E Attribute ID
ATTRIBUTE ACCESS DATA
ID RULES NAME TYPE VALUE
1 Get Macid Uint Dipswitch
2 Get Baud rate USINT Dipswitch
3 Get BOI BOOL 0x01 Auto-Reset 0x00 Hold
4 Get/Set Bus off counter USINT 0x00 (Set) Value (Get)
5 Get Allocation info STRUCT Allocate Serv
DeviceNet Object Instance Attributes:
DeviceNet Object Instance Services:
SERVICE SERVICE CODE PARAMETERS
Get Attribute Single 0x0E Attribute ID
Set Attribute Single 0x10 Attribute ID
Allocate 0x4B Allocation Choice Master MACID
Release 0x4C Release Choice
2.4 Assembly Object (Class ID = 4)
There is a single instance of the Assembly Object for the Chameleon DeviceNet Status Indicator. No class attributes
or services are supported for the Assembly Class.
Assembly Object Instance Attributes:
ATTR ACCESS DATA
ID RULES NAME TYPE VALUE
3 Get/Set Data Struct See Sect 1.5
Assembly Object Instance Services:
SERVICE SERVICE CODE PARAMETERS
Get Attribute Single 0x0E Attribute ID
Set Attribute Single 0x10 Attribute ID
2.2 Message Router Object (Class ID = 2).
There is no externally visible interface to the Message Router Object.
2.3 DeviceNet Object (Class ID = 3).
There is a single instance of the DeviceNet Object for the Chameleon DeviceNet Status Indicator.
DeviceNet Object Class Attributes:
ATTRIBUTE ACCESS DATA
ID RULES NAME TYPE VALUE
1 Get Revision Uint 0x0002
