1.1 DESCRIPTION OF THE MACHINE
The Seed Hawk

aircart is a single axle cart which is available as a tow between or a
tow behind except the 800 aircart which is only available in the tow behind
configuration. The 400 aircart is 400 bushels, with two compartments in a 60/40 split.
The 500, 600 and 800 bushel aircarts have three compartments and a standard two
fan configuration. The meters are designed to utilize each compartment for high
efficiency by being able to divert the product into either the seed or fertilizer air stream.
Multiple rollers are available for each meter which gives the meter the capability of
accurately dispensing every type of product, from low amounts of canola to high rates
of fertilizer. A Vaderstad infinitely adjustable gearbox is standard on every meter, but
there is the option to upgrade to a hydraulic drive system controlled by a Raven Viper
touchscreen computer.
1.2 ILLUSTRATION OF THE MACHINE
Model 800 shown in Figure 1 with a 10 inch fill auger and optional bag lift.
Figure 1: 800 Bushel Model
WARNING! Some pictures in this Operator’s Manual show the machine
with shields removed to better show the subject of the picture. The Seed
Hawk

aircart must NEVER be operated with any of the shields either
opened or removed. Ensure that ALL shields are attached, closed and in
good working condition prior to operating the Seed Hawk

aircart.
