Seed Hawk
®
Manual Aircart Page 20
4.2.2 Operating the Auger
1. Ensure that all screens and
shrouds are in place and that the
cleanout gate, on the bottom of
each meter, is closed, Figure 8.
2. Activate tractor hydraulic circuit
#4, and pull the diverter valve up
to the auger circuit.
3. The handle on the auger tube is
the control to operate the auger
flighting in a forward or reverse
direction.
4. Whether filling or unloading the
aircart, the auger performs at its
highest capacity when product is
falling directly into the flighting.
4.2.3 Auger Position for Unloading Aircart
1. Using your remote, allow the
auger tube to pivot under any of
the aircart compartments in order
to empty them,
Figure 9.
2. Loosen the cross thumb-nuts on
the cleanout gate, Figure 8, and
slide it up to allow product to fall
between the airstream tubes.
3. Once emptied, the bottom
airstream door can be removed
for complete cleanout below the
meter.
Figure 8
Figure 9
