Page 13
3.0 SPECIFICATIONS
3.1 HARDWARE TORQUE
Note: Torque 30.5L32 tire lug nuts to 475 Nm (350 lb-ft)
3.1.1 SAE
Bolt Diameter
Bolt Torque
inches
SAE 5
N·m (lb-ft)
SAE 8
N·m (lb-ft)
1/4
11 (8)
16 (12)
5/16
23 (17)
33 (24)
3/8
41 (30)
61 (45)
7/16
68 (50)
95 (70)
1/2
110 (80)
155 (115)
9/16
149 (110)
210 (155)
5/8
203 (150)
285 (210)
3/4
366 (270)
508 (375)
7/8
536 (395)
827 (610)
1
800 (590)
1234 (910)
3.1.2 Metric
Bolt Diameter
Bolt Torque
mm
8.8
N·m (lb-ft)
10.9
N·m (lb-ft)
M3
0.5 (0.4)
1.8 (1.3)
M4
3 (2.2)
4.5 (3.3)
M5
6 (4)
9 (7)
M6
10 (7)
15 (11)
M8
25 (18)
35 (26)
M10
50 (37)
70 (52)
M12
90 (66)
125 (92)
M14
140 (103)
200 (148)
M16
225 (166)
310 (229)
M20
435 (324)
610 (450)
M24
750 (555)
1050 (774)
M30
1495 (1103)
2100 (1550)
M36
2600 (1917)
3675 (2710)
3.1.3 Flare-Type Tube Fittings
Tube Size
OD
in
Nut Size
across flats
in
Torque
N·m (lb-ft)
Recommended #
Turns (after
finger tightening)
turns (flats)
3/16
7/16
8 (6)
1/6 (1)
1/4
9/16
12 (9)
1/6 (1)
5/16
5/8
16 (12)
1/6 (1)
3/8
11/16
24 (18)
1/6(1)
1/2
7/8
46 (34)
1/6 (1)
5/8
1
62 (46)
1/6 (1)
3/4
1-1/4
102 (75)
1/8 (0.75)
7/8
1-3/8
122 (90)
1/8 (0.75)
