Manual Aircart Page 21
4.2.4 Auger Transport Position
NOTE
1. Position the auger so that the
tube is resting on the locking
mechanism at the back of the
aircart. In TBH configurations
only, the hopper can be rotated
down for transport,
: Fill auger should always be
secured for transport, no matter
how short the distance. Clean out
auger prior to transport or
storage.
Figure 10.
2. The locking mechanism must be
used to secure auger when
transporting at all times, Figure
11.
3. Be sure to secure locking
mechanism by replacing pin,
Figure 12.
4. Lift and swing handle in towards
the aircart, then pull down to
secure it. Push the auger diverter
valve back to the fan position.
Figure 10
Figure 11
Figure 12
