4.6 HYDRAULIC CONNECTIONS
Tow Between Aircart Decal 1
Opener Up
Wing Up
SCT Meter Supply
Not Used
Tow Between Aircart Decal 2
Opener Down
Wing Down
SCT Meter Return
Toolbar Dump
Tow Behind Aircart Decal 1
Fan 1 Pressure
Fan 2 Pressure
Meter Gate Pressure
Hydraulic Drive
Pressure
Tow Behind Aircart Decal 2
Fan 1 Return
Fan 2 Return
Mater Gate Return
Dump to Tank
