Part No. 4801-5138 Rev 11-05

Rollup Curtain System

Page 6

SINGLE SYSTEM

Bracket
0404-8781

Back Wind Pipe
See Parts List

5

′

Front Wind Pipe
See Parts List

Conduit straps
1030-5002

4. Physical Description/Drawing















































Brackets
See parts list

Back Wind Pipe
See Parts List

Universal

Conduit pipe

0.922" (2.34 cm) O. D.

See Parts List

Curtain pipe
1.315" (3.34 cm) O. D.
See Parts List

Cabling not shown in this diagram. Refer to Section 13 for Cabling setup.

Curtain

Front Wind Pipe
See Parts List

DOUBLE STACK

SYSTEM

Pockets enclose openings between the
curtain and building (Kits available)

NOTE: Two different
drives are used.
(1) Rack & pinion
(2) Gear box
