Environmental considerations
For optimal performance, operate or store the power supplies in compliance with the following
environmental conditions.
Power supply consumption
lists the maximum power supply consumption for each FastIron GS model.
lists the maximum power supply consumption for each FastIron GS-STK model.
TABLE 20
Power Supply Operating and Storage Environment
Description
Range
Operating Environment
Operating temperature
32
– 104
F (0
– 40
C)
Relative humidity
0 – 95%, non-condensing
Operating altitude
Up to 10,000 feet above sea level
Operating noise
47 – 51 dBA
Cooling
•
AC: internal fans, 50mm
•
DC: internal fan, 60 mm
Storage Environment
Storage temperature
-40
to 185
F, -40
to 85
C
Storage humidity
95% maximum, non-condensing
Storage altitude
Up to 15,000 feet above sea level
TABLE 21
Maximum Power Supply Consumption for FGS Models
Model
Maximum Power
Consumption
FGS624
without uplink
with 2 CX4+iXFP
with 2 XFP+1XFP
with Combo+1XFP
48 W
63 W
67 W
65 W
FGS648
without uplink
with 2 CX4
with 2XFP
with Combo
94 W
102 W
106 W
104 W
FGS624 power drawn from outlet with 1 power supply
without uplink
with 2 CX4+1XFP
with 2XFP+1XFP
with Combo+1XFP
99 W
121 W
121 W
121 W
