Brocade FastIron GS and GS-STK Hardware Installation Guide 75
53-1002186-02
Power supply specifications
6
DRAFT: BROCADE CONFIDENTIAL
• RPSDC-FGS (DC power supply)
DANGER
The power supplies used with POE devices produce extensive power to support 802.3af
applications. Installing the power supply in a device other than a POE device will cause extensive
damage to your equipment.
DANGER
The power supplies can be swapped in or out of the device while the device is running. You can
remove and insert a power supply without opening the device. If the device contains two power
supplies and the power supplies are redundant, you can remove one of the power supplies
without interrupting operation. The remaining power supply provides enough power for all the
ports.
NOTE
A FastIron GS or GS-STK POE device with dual power supplies may not provide redundancy,
depending on how much power the POE ports are consuming. Refer to
“Power specifications for
POE” on page 15.
DANGER
Remove the power cord from a power supply before you install it in or remove it from the device.
Otherwise, the power supply or the device could be damaged. The device can be running while a
power supply is being installed or removed, but the power supply itself should not be connected
to a power source.
All power supplies are auto-sensing and auto-switching.
Key features
Refer to “Power supplies” on page 14 for the key features of the FGS power supplies.
Physical dimensions and weight
TABLE 19 Physical Dimensions and Weight of Power Supplies
Power Supply Dimensions Weight
RPS-FGS
RPSDC-FGS 6.25 cm (H) x 22.03 cm (W) x 19.30 cm (D)
2.46 in (H) x 8.67 in (W) x 7.6 in (D)
3.016 kg (6.65 lbs)
2.72 kg (6 lbs)
