38 Brocade FastIron GS and GS-STK Hardware Installation Guide
53-1002186-02
Attaching a PC or terminal
2
DRAFT: BROCADE CONFIDENTIAL
FIGURE 33 Serial port pin and signalling details
Most PC serial ports also require a cable with a female DB-9 connector.
Terminal connections will vary, requiring either a DB-9 or DB-25 connector, male or female.
Serial cable options between a Brocade switch or router and a PC or terminal are shown in
Figure 34 .
NOTE
As indicated in Figure 33 and Figure 34 , some of the wires should not be connected. If you do
connect the wires that are labeled “Reserved”, you might get unexpected results with some
terminals.
FIGURE 34 Serial port pin assignments with connection options to a terminal or PC
Pin Assignment
DB-9 mal
Pin Number Switch Signal
6
1 Reserved
2 TXD
(output)
3 RXD (input)
4 Reserved
5 GND
6 Reserved
7 Reserved
8 Reserved
9 Reserved
1 5
9
e
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
8
3
2
20
7
6
4
5
22
1
2
3
4
5
6
7
8
9
DB-9 to DB-9
Female Switch Terminal or PC
Reserved
Reserved
Reserved
Reserved
DB-9 to DB-25
Female Switch
Terminal or PC
Reserved
Reserved
Reserved
Reserved
