Page 45

Console serial RJ45 management port pinouts (Continued)
TABLE 13
Pin number
Definition
Notes
7
NC
8
NC
Cable specifications
For information about supported transceivers and cable lengths and types, refer to the following
Brocade website at:
NOTE
Cable installation and network configuration affects overall transmission capability. For network-specific
recommendations, consult your local Brocade reseller or system engineer.
Power cords
NOTE
Brocade recommends that you use the power cord that is shipped with the device.
For an ICX 6430-C device to operate at 100V, the power cord should be C13 type connector with 10A
rating or better (NEMA-5-15 plug).
For an ICX 6430-C device to operate at 240V, the power cord should be C13 type connector with 10A
rating or better.
All devices ship with United States compatible power cords at the time of order. United Kingdom- and
European-compatible power cords are also available.
Cable specifications
Brocade ICX 6430-C Compact Switch Hardware Installation Guide
43
53-1003080-01
