Network connection-related LED states (Continued) TABLE 4
LED Desired
state Meaning Abnormal
state Meaning or action
SFP(F1 - F2,
Slot 3) On or
flashing
(Green) The SFP port is
operating.
Flashing green
indicates the port
is transmitting
and receiving
user packets. Off A link is not established with the remote port.
You can do the following:
• Verify that the connection to the other
network device has been properly made.
Also, make certain that the other network
device is powered on and operating
correctly.
• Verify that the transmit port on the device is
connected to the receive port on the other
network device, and that the receive port on
the device is connected to the transmit port
on the other network device. If you are not
certain, remove the two cable connectors
from the port connector and reinsert them in
the port connector, reversing their order.
• Dust may have accumulated in the cable
connector or port connector.
• Verify that the port has not been disabled
through a configuration change.
• If the other actions do not resolve the
problem, try using a different port or a
different cable.
Uplink ports
(C1-C2, Slot 2)
On or
flashing
(Green) The ports are
operating.
Flashing green
indicates the port
is transmitting
and recieving
user packets. Off A link is not established with the remote port.
You can do the following:
• Verify that the connection to the other
network device has been properly made.
Also, make certain that the other network
device is powered on and operating
correctly.
• Verify that the port has not been disabled
through a configuration change. You can
use the CLI. If you have configured an IP
address on the device, you also can use the
Web management interface or Brocade
Network Advisor.
• If the other actions do not resolve the
problem, try using a different port or a
different cable.
If a problem persists after taking these actions, contact Brocade Technical Support.
