ICX6430-C Installation
● Items included with an ICX 6430-C device..................................................................... 17
● Summary of installation tasks......................................................................................... 18
● Installation precautions................................................................................................... 18
● Preparing the installation site.......................................................................................... 19
● Installing the device.........................................................................................................20
● Powering on the system..................................................................................................35
Items included with an ICX 6430-C device
DANGER
The procedures in this manual are intended for qualified service personnel.
DANGER
Before beginning the installation, see the precautions in Power precautions on page 19.
The device ships with all of the following items included in your shipping container. Verify the contents
of your shipping container. If any items are missing, contact the place of purchase.
• ICX 6430-C device
• Wall mounting kit containing two wall-mount screws and two plastic anchors
• One AC power cord - US only
• Power cable clip
• Console cable
• Four rubber feet
• China ROHS sheet
• Read Me First document
• Wall Mount Holes Location template (single sheet)
Additional mounting options available for order include the following:
• A wall mount option is available to order for a secure wall mount, in addition to the basic wall
mount.
• An additional rack-mounting kit is available to order to mount the device in a two-post rack.
• A magnet mount option is available to order to mount the device securely on a metal surface.
