Hardware Specifications
● AC power supply specifications...................................................................................... 41
● Physical dimensions and weight..................................................................................... 41
● Environmental considerations......................................................................................... 42
● Pinouts and signalling..................................................................................................... 42
AC power supply specifications
All devices ship with one embedded AC power supply unit with a standard IEC type (IEC320) input
connector, operating universal or wide input.
ICX 6430-C AC Power specifications TABLE 7
Model Input voltage range (AC) Internal power supply rating (watts)
ICX 6430-C12 100 - 240 V 100 Watts
ICX 6430-C MAX Power with 100% Traffic Throughput and Maximum PoE Load TABLE 8
AC Input
Voltage Switch Only
Consumption
Input Current Switch Only
Consumption
Input Watts Switch
BTU/Hr Switch &
PoE AC
Input
Current Switch &
PoE Input
Watts Total
BTU/Hr
100VAC 0.40 Amp 17.71 W 60.25 0.94 Amp 91.69 W 372.84
120VAC 0.34 Amp 17.66 W 60.08 0.79 Amp 91.18 W 370.93
200VAC 0.25 Amp 17.86 W 60.76 0.50 Amp 92.05 W 374.58
240VAC 0.22 Amp 18.11 W 61.61 0.43 Amp 92.60 W 377.30
Physical dimensions and weight
ICX 6430-C12 Physical dimensions and weight TABLE 9
Model Height Width Depth Weight
ICX 6430-C12 43.94 mm
(1.73 in.)
269.24 mm
(10.6 in.)
213.36 mm
(8.4 in.)
1.9 kg
(4.19 lbs)
